The company's products include extraction equipment and units, stainless steel reactor, concentrated evaporation equipment, alcohol recovery equipment, non-standard pressure vessels, storage tanks, large infusions, small injection preparation equipment, stainless steel fermentation tanks, stainless steel valves, pipe fittings and other products, product quality Meet the requirements of GMP standards for pharmaceutical production.
We are striving for progress, innovation, and constantly introducing pharmaceutical machinery with advanced domestic and international standards. The equipment for extracting concentrated products is mainly sold throughout the country.
The products are mainly used in the pharmaceutical industry, bioengineering, fine chemical industry, food industry, The brewing industry and other projects that require high requirements for stainless steel equipment and strict hygiene requirements.
Dimension: Customized
Material: 304 or 316 stainless steel or Carbon steel
Surface: Mirror, Matt, or mill finish.
Certificate: ISO 9001
Performance characteristics
(1) High filtration precision and uniform filter aperture
(2) The filter resistance is small, the flux is large, the interception ability is strong, and the service life is long.
(3) The filter material has high cleanliness and no pollution to the filter media.
(4) Chemical solvents such as acid and alkali.
(5) High strength, high temperature resistance, and the filter element is not easily deformed.
(6) Low price, low operating cost, easy to clean, and filter cartridges can be replaced.
Regular Size
Effective volume (L)
|
Dimension of tank (d×h ) (mm×mm)
|
Total height (mm)
|
DiameterOf inlet
|
Heat preservation layer (for dual-layer tank)(mm)
|
& outlet | ||||
500
|
840 × 1000
|
2250
|
38
|
60
|
600
|
920 × 1000
|
2300
|
38
|
|
700
|
990 × 1000
|
2300
|
38
|
|
800
|
950 × 1220
|
2500
|
38
|
|
900
|
1010 × 1220
|
2500
|
38
|
|
1000
|
1060 × 1220
|
2550
|
51
|
|
1500
|
1160 × 1500
|
2850
|
51
|
|
2000
|
1340 × 1500
|
2900
|
51
|
|
3000
|
1410 × 2000
|
3400
|
51
|
|
4000
|
1620 × 2000
|
3450
|
51
|
|
5000
|
1810 × 2000
|
3500
|
51
|
|
6000
|
1980 × 2000
|
3550
|
51
|
|
7000
|
1930 × 2440
|
4000
|
51
|
|
8000
|
2060 × 2440
|
4000
|
51
|
|
9000
|
2180 × 2440
|
4050
|
51
|
|
10000
|
2300 × 2440
|
4050
|
51
|
|
12000
|
2270 × 3000
|
4600
|
51
|
|
15000
|
2530 × 3000
|
4700
|
51
|
|
20000
|
2640 × 3660
|
5400
|
51
|
Application
1.Used as disinfection tank,liquid composing tank,temporary storage tank and liquid blending tank etc.
2.Ideal in fields such as foods,dairy products,fruit juice beverages,pharmacy,chemical industry and biological engineering etc.
